NBSANMINSE 3V Series G Thread Solenoid Valve Pneumatic Control Valve Single Double Coil Pneumatic Valve AIRTAC Type
The images shown are not all the actual item and are for your reference only
| Working medium | 40 Micron Filtered Air |
| Action mode | Internally pllot-actuated |
| The use of pressure | 0.15~0.8MPa |
| Max. poof pressure | 1.2MPa |
| Working temperature | -5~50℃ |
| Voltage range | ± 10% of rated voltage |
| Insulation& Protection class | Class F. IP65 |
| Connection form | Line type or terminal type |
| Highest action frequency | 5 cycle/second |
| Shortest excitation time | 0.05 Second |
FAQ
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What ' s your business scope ?
A: Our business scope is SMC type high quality cylinder , air source treatment , solenoid valve ,water valve,steam valve, mechnical valve ,foot valve,angle seat valve,anti-explosion valve,pluse vlave, pneumatic valve ,hydraulic ball valve,hydraulic ss ball valve,hydraulic check valve,hydraulic solenoid valve ,all type of coil,lubrication pump and parts,SS316 fitting,quick coupler , etc .
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Why choose us
1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .
Product Tags:
|
|
NBSANMINSE 3V Series G Thread Solenoid Valve Pneumatic Control Valve AIRTAC Type Images
|
