GE Manifold Assembly Air Multi Needle Valve Island With Electrical Control Box

Brand Name : NBSANMINSE

Model Number : GST,GE manifold assembly，Multi-pin/IO-link electrical control box，Electrical Junction Box

Place of Origin : China

Certification : CE

MOQ : 1

Payment Terms : L/C, T/T

Supply Ability : 1000000

Delivery Time : 5-30days

Packaging Details : EXPORT PACKAGE

Valve type : 1:1000,2:2000

Takeover method : Plate valve，outlet on the side of the manifold

Working Pressure : 0.15~0.8MPa

Ambient temperature : -5~60

Working medium : Air

Contact Now

Features:

This series of multi needle valve groups adopts a containerized structural design, which is connected to the valve group through a multi stranded cable with a multi pin plug. It has the characteristics of convenient wiring and piping, small volume, and easy installation. Compared with conventional connection methods, the interface of a multi pin interface valve group is simplified to a multi pin plug and a multi stranded cable, eliminating the need for a terminal block. Specially suitable for PLC and bus control, the number of valve groups can be selected from 4 to 24 groups, with integrated installation cables and connection ports using 25 pin D-Sub leads to thicken the common line. Aluminum base plate, hard oxidation, corrosion resistance, protection level IP65.

GE Manifold Assembly Air Multi Needle Valve Island With Electrical Control Box

GE Manifold Assembly Air Multi Needle Valve Island With Electrical Control Box

GE Manifold Assembly Air Multi Needle Valve Island With Electrical Control Box

GE Manifold Assembly Air Multi Needle Valve Island With Electrical Control Box
